Welding Fume Extraction Systems

Connecting the Fume-A-Vent simple drop system to the vehicle exhaust tailpipe is as easy as 1 2 3. Number 1 - Release the rope clip to lower the lifting elbow. Number 2 - Disconnect the lifting elbow from the rope clip. Number 3 - Remove the red plug from the tailpipe adapter. And connect it to the tailpipe. To disconnect and store the system simply reverse the process. Disconnect, insert the red plug into the tailpipe adapter, connect the lifting elbow to the hanging rope clip, pull the rope, and connect it to the eye hook.
